Fuji FDR AQRO Portable X-Ray
Fuji FDR AQRO Portable X-Ray
A compact, ultra-maneuverable portable digital X-ray system engineered for tight clinical spaces, delivering high-resolution DR imaging with advanced low-dose processing for fast, confident diagnostics at the point of care. Its slim profile, motor-assisted drive, and intuitive touchscreen interface streamline workflow across ICUs, ERs, ORs, and bedside environments while maintaining exceptional image quality and operational efficiency.
Questions?
Collapsible content
Product Description
Fujifilm FDR AQRO Portable X-Ray System – Compact Power for True Point-of-Care Imaging
The Fujifilm FDR AQRO Portable X-Ray System is an ultra-compact, lightweight digital radiography solution designed for rapid, high-quality imaging at the point of care. Engineered for maximum portability and ease of use, the FDR AQRO delivers the performance of a full-scale digital X-ray system in a streamlined, mobile platform ideal for hospitals, outpatient clinics, orthopedic offices, and specialty practices.
With its integrated console, wireless flat panel detector compatibility, and advanced Fujifilm image processing technology, the FDR AQRO enables clinicians to capture diagnostic-quality images quickly and efficiently — without the need for a dedicated X-ray room.
Key Features of the Fujifilm FDR AQRO
-
Ultra-Compact & Lightweight Design
Small footprint and maneuverable structure allow easy transport between rooms and tight clinical spaces. -
High-Frequency X-Ray Generator
Provides consistent exposure performance and reliable image acquisition. -
Wireless Flat Panel Detector Compatibility
Enables fast image capture and immediate preview for improved workflow. -
Integrated Acquisition Console
Built-in touchscreen display simplifies exam setup, image review, and data management. -
Advanced Digital Image Processing
Fujifilm’s proprietary processing enhances contrast, sharpness, and noise reduction for superior diagnostic confidence. -
Battery-Powered Mobility
Designed for flexible, point-of-care imaging without dependency on fixed infrastructure. -
DICOM Connectivity
Seamless integration with PACS, RIS, and hospital networks for efficient image transfer and storage.
Ideal Clinical Applications
The FDR AQRO Portable X-Ray System is ideal for:
- Orthopedic Clinics
- Sports Medicine Practices
- Urgent Care Centers
- Outpatient Facilities
- Bedside & Room-to-Room Imaging
- Post-Operative Imaging
Its portability makes it especially valuable for facilities requiring flexible imaging without investing in a full X-ray suite.
Why Choose the Fujifilm FDR AQRO?
The FDR AQRO delivers the perfect combination of:
- Portability and maneuverability
- High-resolution digital imaging
- Efficient workflow design
- Compact storage footprint
- Reliable Fujifilm imaging performance
Backed by Fujifilm’s trusted expertise in digital radiography, the FDR AQRO empowers healthcare providers with fast, accurate imaging wherever it’s needed.
Upgrade Your Point-of-Care Imaging with the Fujifilm FDR AQRO
If you’re looking for a portable digital X-ray system that combines power, efficiency, and space-saving design, the Fujifilm FDR AQRO is a smart and flexible solution.
Specifications
FUJIFILM FDR AQRO
Compact Mobile Digital X-Ray System
Technical Specifications
SYSTEM OVERVIEW
- Product Name: FDR AQRO
- Model Number: DR-XD1000
- Compact, integrated mono-tank mobile X-ray system
- Designed for bedside and portable imaging
- Ultra-lightweight design (approximately 80% lighter than traditional mobile systems)
- Integrated DR detector storage, charging, and registration
POWER SUPPLY
- Input Power: 100–240 V AC
- Single Phase: 50–60 Hz
- Current: 8–3.3 A
- AC Plug-in Operation:
– Can operate while plugged in
– Usable even when battery is drained
BATTERY PERFORMANCE
- Lithium-ion battery
- Continuous Use:
– Up to 12 hours (at 20 exposures per hour) - Quick Charge:
– 15-minute charge = up to 1 hour use (20 exposures/hour) - Full Charge Time:
– Approximately 4 hours
X-RAY GENERATOR
- Technique Range: 40–100 kV
- mAs Range: 0.25–100 mAs
- Maximum Rating: 2.5 kW
- Tube Voltage: 40–100 kV
- Tube Current: Max 35 mA
– Maximum voltage at max current: 71 kV
X-RAY TUBE
- Nominal Focal Spot Size: 1.2 mm
- Maximum Anode Heat Capacity: 35 kJ (50 kHU)
- Target Angle: 16°
SYSTEM DIMENSIONS & WEIGHT
- Total Width:
– 21.65" (550 mm) excluding handle
– 23.6" (600 mm) including handle - Total Length: 33.5" (770 mm)
- Total Height: 57.5" (1,460 mm)
- System Weight: 198 lbs (90 kg)
DETECTOR COMPATIBILITY
Compatible with:
- FDR D-EVO III
- FDR D-EVO II
- FDR ES (CsI models)
Available Detector Sizes:
- 10" x 12"
- 14" x 17"
- 17" x 17"
- 24 x 30 cm
Detector Features:
- Patented ISS (Irradiated Side Sampling) reading technology
- Advanced noise reduction circuitry
- Lightweight with tapered edges
- Hydro AG antibacterial coating (D-EVO III & II)
- Higher fluid resistance rating (D-EVO III & II)
- Approx. 2-second image preview
- Approx. 9-second cycle time
IMAGE PROCESSING TECHNOLOGY
- Dynamic Visualization II
– Intelligent density and contrast optimization
– Improved anatomic recognition
– Enhanced PACS window/level flexibility - Virtual Grid (optional)
– Eliminates need for physical grid
– Up to 50% dose reduction compared to grid exams
– Improved patient comfort and positioning - Fujifilm Noise Reduction Circuitry
– 1.7x DQE improvement over previous models
– Effective at doses as low as 0.03 mR
MOBILITY & DESIGN
- 4-way rotating casters
- Ultra-lightweight 198 lb chassis
- Spin-in-place maneuverability
- Front and rear foot latches for locking
- Optional rear-wheel swivel lock
- Compact mono-tank design
- Improved forward and downward visibility
- Cableless tube arm design for easy cleaning
OPTIONAL ACCESSORIES
- Additional storage compartment
- Filter
- Handle height kit
- BCR wireless
- Wipe holder
- Apron hanger
