Oakworks CFPM 400 Table
Oakworks CFPM 400 Table
A cost-effective 4-motion C-arm imaging and pain management table with electric height adjustment, Trendelenburg tilt, longitudinal travel, and lateral tilt — featuring a carbon fiber radiolucent top with up to 56″ metal-free imaging space and a 500 lb capacity for precise, stable positioning during fluoroscopic procedures.
Questions?
Collapsible content
Product Description
Oakworks CFPM400 C-Arm Table – Full 4-Movement Motorized Control with Extended Imaging Surface
The Oakworks CFPM400 C-Arm Table is a top-tier, fully motorized imaging platform designed for advanced interventional pain management, orthopedic procedures, and spine care. Built for precision, comfort, and clinical versatility, the CFPM400 offers four powered movements—height, Trendelenburg tilt, longitudinal travel, and lateral tilt—all controlled with an intuitive multi-function hand control.
Engineered for demanding fluoroscopic environments, the CFPM400 features an extra-long 84" carbon fiber tabletop with a 56" metal-free imaging area, providing exceptional radiolucency for artifact-free C-arm imaging. Its 22” wide surface and 2” Radiolucent Comfort Foam® pad ensure optimal patient support and positioning during extended procedures.
Designed to handle a wide range of clinical applications, the CFPM400 supports up to 500 lbs, includes locking 4” casters for mobility, and comes equipped with patient straps and a crescent face rest pad for additional comfort when using an integrated headrest top. With a robust safety profile and certifications including CE, cETLus, CB, and FDA listing, this table meets the highest standards in clinical care.
Key Features:
-Four Electric Movements – Height (26"–43"), Trendelenburg ±15°/−11°, 10" longitudinal travel, ±15° lateral tilt
-Carbon Fiber Top – 84” long x 22” wide with 56” metal-free imaging space
-Radiolucent Comfort Foam® Pad – 2" thick for superior patient comfort during extended procedures
-Multi-Function Hand Control – Seamless operation of all powered movements
-500 lb Weight Capacity – Sturdy and safe for a wide patient range
-Premium TerraTouch™ Medical Fabric – PVC-free, ISO 10993 certified, easy to clean
-4” Locking Casters – Smooth mobility and secure positioning
-Safety Certified – CE marked, cETLus approved, CB Certificate, FDA listed
-Includes – Patient straps, crescent face rest pad (with headrest top), 4-year parts & 3-year labor warranty
Ideal For:
Specifications
- Carbon Fiber Top - 22" (56cm) wide x 84" (214cm) long
- 56 in. Metal free imaging space
- Motion 1 - Electric Height Range 26 in. - 43 in. (66-109cm) Height Range without pad
- Motion 2 - Electric Trendelenburg Tilt +15°/-11°
- Motion 3 - Electric Longitudinal travel 10 in. (25cm)
- Motion 4 - Electric Lateral tilt ±15°
- Controls - Multi-function hand control
- Weight Capacity - 500lb (227kg)
- Product Weight - 475lb (216kg)
- Included Features - 2 in. (5cm) Radiolucent Comfort Foam® table top pad, 4 in. (10cm) locking casters, Crescent face rest pad (included with integrated headrest top), patient straps (2)
- Warranty - 4 years parts, 3 years labor
- Safety Listings - CE marked, cETLus approved, CB Certificate, FDA Listed
- Fabric - Premium, PVC free TerraTouch™ Medical Grade Fabric is ISO 10993 Certified
Additional Information
- Pain Management
- Orthopedics
- Vascular
- Urology
- Height
- Trendelenberg
- Lateral Tilt
- Longitudinal Travel
