Oakworks CFPM401 C-Arm Table

  • Available New & Refurbished
  • Industry’s Largest Adjustable Height Range of 26″- 44″
  • 56″ Metal Free Imaging Space
  • Integrated Headrest or Rectangular Top Option
  • Cost Effective 4 Movement Table
  • 500 lb Patient Weight Capacity
  • 3 Year Warranty (new only)

Brochures:

Oakworks CFPM401 C-Arm Table Brochure



Description

Like the Oakworks CFPM400 the CFPM401 offers (4) electric movements which include: heigh, trendelenburg, longitudinal travel, but replaces the lateral tilt with lateral travel instead. All Oakworks c-arm/imaging tables are built in the USA and are backed by an industry leading 3 year warranty.

The Equipped MD Difference.

At Equipped MD we guarantee the best possible pricing on all Oakworks products. We will meet or beat any competitors quote, and offer our “wholesale direct” pricing right out of the gate. This allows us to offer you exceptional value, and custom tailor the pricing to your needs & budget. To learn the details and get in-depth pricing simply hit the request a quote button above or simply give us a call.

Included Features:
  • Carbon Fiber Top – 56 in. Metal free imaging space
  • Top Dimensions – 22 in. (56cm) wide x 84 in. (214cm) long – Integrated Headrest Version
  • Top Dimensions – Rectangular 24 in. (61cm) wide x 80 in. (203cm) long – Rectangular Top Version
  • Motion 1 – Electric Height Range 26 in. – 44 in. (66-112cm)
  • Motion 2 – Electric Trendelenburg tilt +15°/-11°
  • Motion 3 – Electric Longitudinal travel 10 in. (25cm)
  • Motion 4 – Electric Lateral travel ±4 in. (10cm)
  • Controls – Multi-function hand control
  • Weight Capacity – 500 lb (227kg)
  • Product Weight – 475 lb (216kg)
  • Included Features – 1in. (3cm) Radiolucent Comfort Foam™ table top pad, 4in. (10cm) locking casters, Crescent face rest pad (included with integrated headrest top), patient safety straps (2)
  • Warranty – 3 years parts, 2 years labor
  • Safety Listings – CE marked, cETLus approved, CB Certificate
Optional Features:
  • Multi-function Foot Control (75074)
  • 2 in. (5cm) Table Top Pad Upgrade (73190-T01) – Upgrade from the standard 1 in. (3cm) pad
  • 5 in. (13cm) casters (65427) – Upgrade from the standard 4 in. (10cm)
Accessories:
  • Arm Hammock (48751-T01) – Use with Integrated Head Rest Top
  • Carbon Fiber Arm Board 6 in. wide (42585) – 180º Articulation
  • Carbon Fiber Arm Board 7.5 in. wide 70337) – 180º Articulation
  • Fluoro Extender (33975) – Polycarbonate
  • Interventional Supine Pillow System (69808-T01) – Contoured pad and support wedge pad
  • Spine Positioning System II (70100-T01) – 8 piece system
  • T-rail Clamp (63336 ) – 6 in. (15cm) long rail

Additional information

Brand

Oakworks

Model

CFPM401

Movements

Height
Trendelenburg
Longitudinal Travel
Lateral Travel

Title
